Specification
- Frequency: 5150-5850 MHz.
- Gain: 17 dBi.
- VSWR: 15 dB.
- Cross-polar Ratio:>20dB (±60°>10).
- Front-to-back Ratio:>23 dB.
- Isolation: <30 dB.
- Intermodulation IM3: <-150dBc.
- Max Input Power: 100 W.
- Impedance: 50 Ohms.
- Lightning Protection: DC Ground.
- Mechanical Data.
- Connector: 2*N Female.
- Dimensions: 566 x 165 x 70 mm.
- Connector position: Bottom.
- Item Weight - 5.51 lbs.
- Reflector Material: Aluminum Alloy.
- Radome Material: UV Resistance PVC.
- Mounting Method: Mast.
- Mast Size: ø40-ø70 mm.
- Rated Wind Velocity: 210km/h.
- Operating Temperature: -40~+65°C.
